Triac and SCR Output Photocouplers MOC3072M
onsemi
MOC3072M
--
Optoelectronics
Triac and SCR Output Photocouplers
Specification
| Product Attribute | Attribute Value |
| HTS | 8541.49.80.00 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| Standard | DIN|EN|UL|VDE |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 6 |
| Automotive | No |
| Lead Shape | Through Hole |
| Output Type | AC |
| PCB changed | 6 |
| Part Status | Active |
| Output Device | Triac |
| Package Width | 6.6(Max) |
| Package Height | 3.53(Max) |
| Package Length | 8.89(Max) |
| Supplier Package | PDIP |
| Standard Package Name | DIP |
| Zero-Crossing Circuit | No |
| Maximum Forward Voltage (V) | 1.5 |
| Maximum Reverse Voltage (V) | 3 |
| Typical Forward Voltage (V) | 1.18 |
| Maximum Forward Current (mA) | 60 |
| Minimum Trigger Current (mA) | 10(Max) |
| Maximum Power Dissipation (mW) | 330 |
| Minimum Isolation Voltage (Vrms) | 4170 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Critical Rate of Rise of Off-State Voltage (V/us) | 1000(Min) |
| Description |
